grade 5 titanium round rod

Origin: Baoji, Shaanxi, China
Brand: FRL Metal
Surface: Polished surface
Grade: Gr5(Ti-6Al-4V) TC4
Diameter: 4–150 mm
Density: 4.51g/cm³
Strength: 950 MPa minimum
Surface: Polished
Standard: ASTM B348/AMS 4928
Packaging Details: Plywood case
Delivery Time: 5~7days
Certification: ISO9001
Application: Aerospace, machining

Send Inquiry

Download

Product Description

Grade 5 Titanium Round Rod - Premium Ti-6Al-4V Alloy Solutions

Product Introduction

Looking for exceptional strength and reliability in your next project? Our grade 5 titanium round rod delivers unmatched performance for demanding applications. Made from premium Ti-6Al-4V alloy, these precision-engineered rods combine superior strength-to-weight ratio with excellent corrosion resistance. Whether you're working in aerospace, medical, or marine industries, our titanium round rods provide the durability and consistency you need for critical applications.

Technical Specifications

Property	Specification
Alloy Type	Ti-6Al-4V (Grade 5)
Diameter Range	4–150 mm
Surface Finish	Polished
Density	4.51 g/cm³
Hardness	36 HRC
Tensile Strength	895-930 MPa
Yield Strength	825-869 MPa
Elongation	10% min

	N	C	H	Fe	O	Al	V	Pa	Mo	Ni
Gr 1	0.03	0.08	0.015	0.2	0.18	/	/	/	/	/
Gr 2	0.03	0.08	0.015	0.3	0.25	/	/	/	/	/
Gr 5	0.05	0.08	0.015	0.4	0.2	5.5~6.75	3.5~4.5	/	/	/

Key Features and Benefits

Superior Strength Performance

Our Ti-6Al-4V alloy offers exceptional mechanical properties. You get outstanding tensile strength while maintaining excellent ductility for complex machining operations.

Corrosion Resistance

These rods resist corrosion in harsh environments. Salt water, acids, and industrial chemicals won't compromise the material integrity over time.

Lightweight Design

At 4.43 g/cm³ density, you achieve significant weight reduction compared to steel alternatives. This translates to improved fuel efficiency and easier handling.

Temperature Stability

Operating temperatures up to 400°C won't affect performance. Your applications maintain reliability across extreme temperature ranges.

Applications and Industries Served

Aerospace Industry

Aircraft components, engine parts, and structural elements benefit from the superior strength-to-weight ratio.

Medical Devices

Surgical instruments, implants, and medical equipment utilize the biocompatible properties of this titanium alloy.

Marine Applications

Propeller shafts, hull components, and underwater equipment resist saltwater corrosion effectively.

Automotive Sector

High-performance racing components and luxury vehicle parts achieve weight reduction without sacrificing strength.

Chemical Processing

Equipment exposed to corrosive chemicals maintains integrity longer with our titanium solutions.

Manufacturing Process

Raw Material Selection

We source premium titanium sponge and alloying elements. Quality starts with the finest raw materials available in the market.

Vacuum Arc Remelting

Our advanced melting process ensures homogeneous alloy composition. This eliminates impurities and creates consistent material properties throughout each rod.

Hot Working

Precision forging and rolling operations develop the optimal microstructure. You receive rods with uniform grain structure and mechanical properties.

Heat Treatment

Controlled annealing processes optimize strength and ductility balance. Each batch meets exact specification requirements.

Precision Machining

Final diameter control and surface finishing deliver ready-to-use products. Your machining operations benefit from consistent dimensions and surface quality.

Contact Information

Ready to discuss your grade 5 titanium round rod requirements? Our team is here to help.

Email: jenny@bjfreelong.com

WhatsApp: +86 13571190943

Contact us today for quotes, technical specifications, or application guidance. We're committed to providing the titanium solutions that power your success.
