TA15 Titanium alloy

TA15 titanium alloy (national standard grade, nominal composition Ti-6.5Al-2Zr-1Mo-1V) is a near-alpha type high-temperature titanium alloy independently developed in China, corresponding to the Russian grade BT20. It is specifically designed for long-term high-temperature service environments below 500℃ and is a key structural material in the aerospace field.

I. Core Performance Characteristics

Alloy Type: Near-α type titanium alloy

Density: 4.45 ~ 4.5 g/cm³ (significantly lightweight advantage)

Long-term operating temperature: 500℃ (up to 550℃)

Instantaneous temperature resistance: Up to 650℃~800℃

Typical mechanical properties:

Room temperature tensile strength: 900 ~ 1100 MPa

500℃ high-temperature strength: ≥ 620 MPa (far superior to TC4)

Main advantages:
Excellent heat resistance and creep resistance: High strength retention at high temperatures, stable long-term service.

Good weldability: Low weld crack sensitivity; joint strength can reach over 85% of the base metal.

Excellent corrosion resistance: Resistant to corrosion from seawater, chloride ions, H₂S/CO₂, and other media.

High specific strength: Low density, high strength, significant weight reduction (approximately 40% lighter than steel). II. Main Applications

1. Aerospace (Core Application)

Aero-engines: High-pressure compressor blades, discs, drums, intermediate casings, and other high-temperature components (operating temperature 450-500℃).

Aircraft structural components: Wing spars, load-bearing frames, fuselage panels, tail fins, high-temperature ducts, thermal insulation supports, etc.

Aerospace equipment: Rocket fuel tanks, engine nozzle expansion sections, satellite propulsion system piping, etc.

2. Shipbuilding and Marine Engineering

Deep-sea equipment: Submarine pressure hulls, deep-sea submersible manned cabins, deep-sea probe frames, etc.

Offshore platforms: Seawater pipelines, valves, pump bodies, heat exchangers, and other corrosion-resistant structural components.

3. Energy and Chemical Industry

Nuclear power: Steam generator components, spent fuel processing equipment.

Oil and gas: Sulfur-resistant downhole tools, high-pressure valves, geothermal well casings, heat exchangers.

New energy: High-pressure hydrogen storage and transportation tanks, LNG cryogenic valves.

4. Other High-End Manufacturing

Automotive: High-temperature components for racing engine, lightweight connecting rods.

Weaponry: Artillery barrel liners, lightweight structures for armored vehicles.

Quality Control and Testing

Each product undergoes rigorous inspection before shipment:

Dimensional Inspection: Precise measurement of thickness, length, and width

Chemical Composition and Mechanical Property Analysis: Third-party testing reports

Surface Inspection: Visual and microscopic inspection for defects

Ultrasonic Testing: Detection of internal defects

Why Choose Us

Technology and Quality: Located in Baoji, China's Titanium Valley, we possess professional production technology and extensive experience in non-ferrous metal manufacturing.

Global Coverage: We provide consistently high-quality products to customers in Australia, South Korea, Germany, the USA, the UK, Malaysia, and the Middle East.

Quality Commitment: We never compromise on quality and are responsible for every product we manufacture.

Technical Support: We have professional personnel overseeing the entire process from raw materials to finished products!

Contact Us

Our team is dedicated to serving you and hopes that every product you purchase will meet your expectations!

Email: lucky@bjfreelong.com

WhatsApp: +86 13335371763

Please contact us for detailed quotations and technical specifications. We look forward to becoming your trusted high-end titanium materials partner.
