titanium alloy plates

Origin: Baoji, Shaanxi, China
Brand: FRL Metal
Surface: Polished surface
Size: Customizable
Thickness: 0.5–100 mm
Density: 4.51g/cm3
Standard: ASTM B265 Grade: Gr5, Gr7, Gr9
Tensile Strength: 950 MPa minimum
Minimum Order Quantity：1pc
Packaging Details:Plywood case
Delivery Time:5~7days
Certification: ISO9001
Payment Terms:T/T

Send Inquiry

Download

Product Description

Premium Titanium Alloy Plates - Superior Strength & Corrosion Resistance

Are you searching for high-performance titanium alloy plates that deliver exceptional strength-to-weight ratios and outstanding corrosion resistance? Baoji Freelong New Material Technology Development Co., Ltd. specializes in manufacturing premium titanium plates that meet the most demanding industrial requirements. Located in China's renowned Titanium Valley, we bring decades of expertise in producing superior-quality metal materials. Our titanium plates are engineered to exceed your expectations in performance, durability, and reliability for critical applications across aerospace, chemical processing, and marine industries.

Product Introduction

Our titanium plates combine exceptional mechanical properties with remarkable chemical resistance. Each plate undergoes precision manufacturing processes to ensure consistent quality and dimensional accuracy.

Key Product Specifications:

Available Grades: Gr5, Gr7, Gr9
Thickness Range: 0.5–100 mm
Manufacturing Standard: ASTM B265
Surface Finish: Polished finish
Primary Applications: Aerospace & chemical industries

Technical Specifications

Property	Grade 5 (Ti-6Al-4V)	Grade 7 (Ti-0.15Pd)	Grade 9 (Ti-3Al-2.5V)
Tensile Strength	895-930 MPa	345 MPa min	620 MPa min
Yield Strength	825-869 MPa	275 MPa min	483 MPa min
Elongation	10% min	20% min	15% min
Density	4.43 g/cm³	4.51 g/cm³	4.48 g/cm³

titanium alloy plates factory

Key Features and Benefits

Superior Corrosion Resistance

Your operations benefit from exceptional resistance to acids, chlorides, and marine environments. This means longer service life and reduced maintenance costs.

Outstanding Strength-to-Weight Ratio

You get maximum structural performance with minimal weight addition. This is crucial for aerospace applications where every gram matters.

Excellent Biocompatibility

Our plates meet medical-grade standards, making them suitable for surgical implants and medical device manufacturing.

Temperature Stability

You can rely on consistent performance across extreme temperature ranges, from cryogenic to high-heat applications.

Applications and Industries Served

Aerospace Industry

Chemical Processing

Marine Applications

Medical Device ManufacturingQuality Control and Testing

Every batch undergoes comprehensive testing protocols:

Chemical Analysis: Ensures precise alloy composition
Mechanical Testing: Verifies tensile and yield strength properties
Ultrasonic Inspection: Detects internal defects
Surface Quality Assessment: Confirms finish specifications

Packaging and Shipping

Your orders receive protective packaging designed for safe international transport. We use moisture-resistant wrapping and wooden crates for overseas shipments.

Standard delivery timeframes:

Domestic orders: 7-15 days
International shipping: 15-30 days

We work with trusted logistics partners to ensure your titanium alloy plates arrive safely and on schedule.

Contact Information

Ready to source premium titanium plates for your next project? Our team is here to help you find the perfect solution.

Email: jenny@bjfreelong.com

WhatsApp: +86 13571190943

Let's discuss how our expertise can benefit your operations. We look forward to building a long-term partnership with you.
