Medical Grade Zirconium Crucible 20ml

Origin: Baoji, Shaanxi, China
Brand: FRL Metal
Surface: polished surface
Density: 6.51g/cm3
Grade: Zr702,Zr705,R60001,R60901
Minimum Order Quantity：1pc
Sample: available
Packaging Details:Plywood case
Delivery Time:5~7days
Payment Terms:T/T

Send Inquiry

Download

Product Description

Baoji Freelong New Material Technology Development Co., Ltd.: Your Trusted Medical Grade Zirconium Crucible 20ml Manufacturer

Baoji Freelong, a leading supplier of high-quality zirconium products, specializes in manufacturing premium Medical Grade Zirconium Crucible 20ml. Our advanced processing capabilities and strict quality control ensure superior performance for critical medical applications. With years of experience serving global markets, we offer reliable OEM solutions and exceptional customer support.

Medical Grade Zirconium Crucible 20ml price

Medical Grade Zirconium Crucible 20ml for sale

Customized Medical Grade Zirconium Crucible 20ml

Product Introduction

Our Medical Grade Zirconium Crucible 20ml is designed to meet the exacting standards of the medical and dental industries. This crucible combines exceptional purity, superior heat resistance, and outstanding corrosion resistance, making it ideal for high-temperature applications in medical device manufacturing and biomedical research.

Technical Specifications

Capacity: 20ml
Grade: Zr702,Zr705,R60001,R60901
Maximum operating temperature: 1800°C
Dimensions: 40mm diameter x 30mm height (customizable)
Wall thickness: 2mm
Weight: Approximately 85g

The common size of low form crucible

Low form Zirconium crucible
Top diameter(mm)	Bottom diameter (mm)	Height (mm)	Wall thickness (mm)	Capacity (ml)
22	18	20	2	3.6ml
26	16	20	2	5.0ml*2mm
30	24	26	2	10ml*2mm
40	26	41	1	30ml*1mm
42	27	42	2	30ml*2mm
42	30	42	1.6	35ml*1.6mm
41	33	42	2	35ml*2mm
43	34	40	1	40ml*1mm
47	40	35	1	45ml*1mm
49	42	36	2	45ml*2mm
48	38	45	3	45ml*3mm
47	40	38.5	1	50ml*1mm
48	40	42	2	50ml*2mm
56	44	50	2	80ml*2mm
AutoFluxer crucible with flanged
48	29	33	2	25ml*2mm
60	36	39	1	50ml*1mm
60	36	43	2	50ml*2mm

Key Features and Benefits

Ultra-high purity: Ensures minimal contamination for critical medical processes
Exceptional heat resistance: Withstands temperatures up to 1800°C
Superior corrosion resistance: Ideal for aggressive chemical environments
Excellent biocompatibility: Meets USP Class VI standards
Durable construction: Long service life, reducing replacement costs
Precision-engineered: Consistent performance for repeatable results

Applications and Industries Served

Medical device manufacturing (implants, surgical tools)
Dental laboratories (zirconia-based prosthetics)
Biomedical research institutions
Advanced ceramics production
Pharmaceutical research and development

Manufacturing Process

Our Medical Grade Zirconium Crucible 20ml undergoes a rigorous manufacturing process:

Raw material selection: Only the highest grade zirconium is used
Precision machining: CNC-controlled for exact dimensions
Surface treatment: Electropolishing for ultra-smooth finish
Heat treatment: Optimizes material properties
Final inspection: Ensures compliance with all specifications

Quality Control and Testing

Each crucible undergoes extensive testing:

X-ray fluorescence (XRF) analysis for material purity
Dimensional accuracy checks
Surface roughness measurements
Leak testing
High-temperature performance validation

Packaging and Shipping

Individual protective cases for each crucible
Foam-lined boxes for secure transportation
Full traceability with lot numbers and certificates of analysis
Express shipping options available worldwide

Why Choose Us

ISO 13485 certified manufacturing facility
Compliance with ASTM F560 zirconium standards
Experienced in-house R&D team for continuous improvement
Flexible production capabilities for both small and large orders
Competitive pricing without compromising on quality

FAQs

Q: What makes your zirconium crucibles medical grade?
A: Our crucibles meet strict purity standards, are manufactured in an ISO 13485 certified facility, and undergo rigorous testing to ensure biocompatibility and performance in medical applications.

Q: Can I get a custom size for my specific needs?
A: Absolutely! We offer full customization services to meet your exact specifications. Contact us with your requirements for a tailored solution.

Q: What is the typical lead time for an order?
A: Standard Medical Grade Zirconium Crucible 20ml orders typically ship within 2-3 weeks. Custom orders may require 4-6 weeks, depending on specifications.

Q: Do you provide material certificates with each order?
A: Yes, every shipment includes a certificate of analysis detailing material composition and quality control results.
