Nitinol memory wire

Application of Nitionl Alloy Menory Wire

 1. It is used for super-elastic memory alloy mobile phone antennas, children's toy antennas, and optical glasses frames. With the development of the times, it is gradually used in the support ring of women's shapewear. It is used as a scientific research material and frequently appears in various science and technology college materials laboratory.

2. One-way shape structure recovery using a single shape memory. Such as pipe joints, antennas, collars, etc.

3. The process of using a single shape memory Shape memory external use random memory function. Thermal components, robot terminals, etc.

4. The application of superelasticity. Such as springs, binding posts, eyeglass frames. The position of memory alloy is made of alloy, the shelf made of different elastic lens barrel materials, the different elastic mirror column and so on. The length in hot water is immediately elongated, and when cold water appears again, it will immediately return to its original shape. In the event of a fire, the triggering device can also form a conduit to prevent burns. The self-made alloy keeps the heating valve inside, when the temperature is off, the temperature is turned on or the heating valve is automatically turned on or off when the temperature is too high.

 5. The biocompatibility of TiNi alloy is very good, and there are quite a lot of medical examples using its shape memory effect and superelasticity. Such as thrombus filters, spinal orthopedic rods, dental orthopedic wires, cerebral aneurysm clips, bone plates, intramedullary needles, artificial joints, contraceptives, heart repair components, micro-pumps for artificial kidneys, etc.

Picture display

​​​​​​​

Used for glasses and jewelry brackets, common sizes: 1.0mm, 1.5mm, 2.0mm, 2.5mm, etc.

Suitable for implanted devices, bone nails, vascular stents, commonly used sizes: 0.1mm, 0.15mm, 0.2mm, etc.

Orthodontics, commonly used sizes: 2.0mm, 2.5mm, 3.0mm, 3.5mm, etc.

Suitable for deep sea fishing, common sizes: 0.3mm, 0.4mm, 0.6mm, 0.7mm, etc.

The active AF temperature is one of the key properties of Nitinol and can determine the effective superelastic properties of the alloy. Although all major Ni contents in the range of 54.5~57.0mass% meet ASTM F2063-12 standard specification, its AF is very sensitive to chemical composition and detailed grading of Nitinol composition is critical. That's why we use detailed and proven Nitinol codes to identify alloys.

The real active AF temperature may very with actual composition and thermo-mechanical history of the product.

Q: What does your company do?

 A: Our company is a professional manufacturer. We mainly produce titanium, zirconium pipe fittings/nickel alloy pipe fittings/stainless steel flanges/nickel alloy flanges/custom pipelines

Q: What advantages does your company have?

A:

(1): High quality and reasonable price.

(2): Rich experience in after-sales service.

(3): Each process will be checked by the responsible QC to ensure the quality of each product.

(4): Professional packaging team to ensure the safety of every package.

(5): Trial orders can be completed within one week.

(6): Samples can be provided upon your request.
