grade 7 titanium rod

Origin: Baoji, Shaanxi, China
Brand: FRL Metal
Surface: Polished surface
Grade: Ti-0.2Pd (Grade 7) TA9
Diameter: 6–120 mm
Density: 4.51g/cm³
Standard: ASTM B348
Packaging Details: Plywood case
Used: in chemical equipment
Delivery Time: 5~7days
Certification: ISO9001

Send Inquiry

Download

Product Description

High-Performance Grade 7 Titanium Rod: Your Premium Solution for Corrosion-Resistant Applications

Looking for exceptional corrosion resistance in demanding environments? Our grade 7 titanium rod delivers superior performance where standard titanium falls short. Manufactured in China's Titanium Valley, these premium titanium rods feature palladium addition for enhanced chemical resistance. With decades of expertise, Baoji Freelong provides reliable solutions for critical applications worldwide. You get consistent quality and precise specifications every time.

Product Introduction

Our grade 7 titanium rods represent the pinnacle of corrosion-resistant materials engineering. Each rod combines pure titanium with carefully controlled palladium content (Ti-0.2Pd) to create exceptional resistance against reducing acids and aggressive chemical environments.

You benefit from our strategic location in Baoji City - China's renowned Titanium Valley. This gives us direct access to premium raw materials and advanced manufacturing facilities. Our production capabilities ensure consistent quality across every order.

Technical Specifications

Alloy Composition: Ti-0.2Pd (Titanium with 0.2% Palladium)

Available Diameters: 6mm to 120mm

Length: Custom lengths up to 6 meters

Standard Compliance: ASTM B348 Grade 7 /TA9

Surface Finish: Pickled or polished options

Tolerance: ±0.1mm diameter precision

Density: 4.51 g/cm³

Melting Point: 1668°C

	N	C	H	Fe	O	Al	V	Pa	Mo	Ni
Gr 1	0.03	0.08	0.015	0.2	0.18	/	/	/	/	/
Gr 2	0.03	0.08	0.015	0.3	0.25	/	/	/	/	/
Gr 5	0.05	0.08	0.015	0.4	0.2	5.5~6.75	3.5~4.5	/	/	/
Gr 7	0.03	0.08	0.015	0.3	0.25	/	/	0.12~0.25	/	/
Gr 9	0.03	0.08	0.015	0.25	0.15	2.5~3.5	2.0~3.0	/	/	/
Gr12	0.03	0.08	0.015	0.3	0.25	/	/	/	0.2~0.4	0.6~0.9

Key Features and Benefits

Superior Corrosion Resistance

The palladium addition makes these rods exceptionally resistant to reducing acids, including hydrochloric and sulfuric acid solutions. You get reliable performance in environments where standard titanium grades fail.

Excellent Mechanical Properties

Our rods maintain outstanding strength-to-weight ratios while offering excellent ductility and formability. This combination allows for complex fabrication requirements without compromising structural integrity.

Temperature Stability

These titanium rods perform consistently across wide temperature ranges, maintaining their properties from cryogenic conditions to elevated temperatures.

Biocompatibility

Grade 7 titanium offers excellent biocompatibility, making it suitable for medical implants and pharmaceutical processing equipment.

Applications and Industries Served

Chemical Processing Industry

Your chemical plants benefit from our rods' exceptional resistance to aggressive chemical environments. Common applications include heat exchanger tubes, reactor vessels, and piping systems.

Marine and Offshore

The superior corrosion resistance makes these rods ideal for seawater applications, offshore platforms, and marine equipment components.

Medical and Pharmaceutical

Our biocompatible grade 7 titanium rod serves medical device manufacturing, pharmaceutical processing equipment, and surgical instrument production.

Aerospace and Defense

Critical components requiring both strength and corrosion resistance find these rods essential for long-term reliability.

Manufacturing Process

Raw Material Selection

We source premium titanium sponge and high-purity palladium from certified suppliers. Each batch undergoes rigorous incoming inspection.

Melting and Alloying

Our vacuum arc remelting process ensures homogeneous alloy distribution and eliminates impurities. Multiple remelting cycles guarantee consistent composition.

Hot Working

Controlled hot forging and rolling processes develop optimal microstructure and mechanical properties. Temperature and deformation parameters follow strict protocols.

Machining and Finishing

Precision machining achieves tight dimensional tolerances. Surface finishing options include pickling for industrial applications or polishing for high-purity requirements.

Contact Information

Ready to discuss your grade 7 titanium rod requirements? Our team stands ready to help you find the perfect solution.

Email: jenny@bjfreelong.com

WhatsApp: +86 13571190943

Contact us today for detailed specifications, pricing, and technical consultation. We're committed to delivering the highest quality titanium products for your critical applications.
