Titanium welding wire

Origin: Baoji, Shaanxi, China Brand: FRL Metal Name: Titanium Welding Wire Grade: Gr1, Gr2 Density: 4.51g/cm³ Thickness: 0.01–60mm Size: Customized Standards: ASTM, DIN, EN Manufacturing Process: Hot Rolled, Cold Rolled Surface Treatment: Pickled/Bright Certification: ISO9001 Delivery Time: 5-7 days Payment Method: Wire Transfer (T/T) Packaging: Standard Packaging

Send Inquiry

Download

Product Description

Titanium Welding Wire Product Introduction Titanium welding wire is a special welding filler material made from industrial pure titanium or titanium alloys through a complete process including vacuum melting, hot working, multi-pass precision cold drawing, vacuum heat treatment, and ultra-clean surface treatment. It is divided into two main categories: solid titanium welding wire (the industry mainstream) and flux-cored titanium welding wire. With its mechanical properties highly matched to the base material, extreme corrosion resistance, and excellent weldability, titanium welding wire is a core consumable for welding titanium and titanium alloy structures, and a key basic material for welding under extreme conditions in aerospace, chemical corrosion protection, marine engineering, and high-end medical fields.

I. Core Grades and Classifications Based on chemical composition, performance, and applicable scenarios, titanium welding wire can be divided into three main categories: industrial pure titanium welding wire, corrosion-resistant titanium alloy welding wire, and high-strength titanium alloy welding wire. The mainstream grades all correspond one-to-one with national standards and international AWS standards, making them universally accepted choices for global trade and engineering applications. Key information is shown in the table below:

Product Category	National Standard Grade	Core Component Characteristics	Core Properties	Compatible Base Materials	Core Applicable Scenarios
Industrial pure titanium welding wire	Gr1	Ti≥99.5%, extremely low impurities, optimal plasticity	Good weld formation, excellent toughness, and balanced corrosion resistance	Gr1, Gr2 Pure Titanium Base Material	Welding of electronic vacuum devices, precision instruments, and cryogenic containers
Industrial Pure Titanium Welding Wire	Gr2	Ti≥99.2%, balanced strength and ductility	Most versatile, wide welding process window, excellent corrosion resistance	Gr1, Gr2、Gr3 Pure Titanium Base Materials	Chemical corrosion protection, heat exchange equipment, pipeline welding (most widely used grade in the industry)
Corrosion-resistant titanium alloy welding wire	Gr7	Ti-0.2Pd, with added palladium	Significantly improved resistance to crevice corrosion; corrosion resistance in strongly reducing acid environments far exceeds that of pure titanium	Gr7 Gr12, Gr2 corrosion-resistant titanium base materials	Welding of equipment in hydrometallurgical, chlor-alkali chemical, and high-temperature hydrochloric acid environments
Corrosion-resistant titanium alloy welding wire	Gr12	Ti-0.3Mo-0.8Ni	Creep resistant, resistant to high-pressure water corrosion, medium and high temperature strength superior to pure titanium	Gr12, Gr2Pure titanium base material	Seawater desalination, nuclear power condensers, marine engineering, high-temperature heat exchange equipment welding
High-strength titanium alloy welding wire	Gr5	Ti-6Al-4V, α+β dual-phase alloy	High strength and high toughness, weld joint strength matching degree with base material ≥90%, excellent comprehensive mechanical properties	Gr5 medical titanium alloy base material	Aerospace structural components, military equipment, high-end medical implants, lightweight high-end manufacturing

II. Core Performance Characteristics The core performance of titanium welding wire revolves around two main aspects: welding adaptability and service stability. Its key characteristics, distinguishing it from carbon steel and stainless steel welding wires, are as follows:

Superior Welding Process Performance: Annealed titanium welding wire exhibits excellent plasticity, ensuring smooth wire feeding without jamming or breakage. Under standard inert gas protection, the welding arc is stable, the molten pool has good fluidity, and the weld formation is aesthetically pleasing with no spatter. It is suitable for all welding processes, including manual TIG welding, automated MIG welding, robotic welding, and plasma welding.

Exceptional Resistance to Corrosion Media: After weld formation, a dense and continuous titanium dioxide passivation film is formed. From room temperature to 200℃, its corrosion resistance to seawater, nitric acid, organic acids, dilute sulfuric acid, and strong alkalis far exceeds that of 304/316L stainless steel, making it suitable for long-term service conditions involving strong corrosion, such as in chemical and marine environments.

Stable mechanical property matching: The welded joint exhibits high matching degree of strength, plasticity, and toughness with the base material, with no significant performance degradation; the room temperature tensile strength of industrial pure titanium welding wire welds is ≥345MPa, and the elongation is ≥20%; the tensile strength of TC4 alloy welding wire welds is ≥895MPa, and the elongation is ≥10%, meeting the mechanical requirements of pressure-bearing and load-bearing structures.

Strict cleanliness and anti-contamination characteristics: The finished welding wire undergoes multiple cleaning processes, with no oxide film, oil, or hydrogen, oxygen, or nitrogen impurities remaining on the surface; titanium readily reacts with oxygen, hydrogen, nitrogen, and carbon above 400℃. Qualified titanium welding wire can minimize the risk of weld embrittlement, porosity, and cracking, ensuring the long-term stability of the welded joint.

Basic physical parameters: density 4.51g/cm³, melting point 1668℃, coefficient of thermal expansion 8.6×10⁻⁶/℃, thermal conductivity at room temperature 15.24W/(m・K), non-magnetic, suitable for non-magnetic working conditions such as nuclear magnetic resonance equipment and precision electronics.

Quality Control & Testing

Each product undergoes rigorous inspection before shipment:

Dimensional Inspection: Precise measurement of thickness, length, and width

Chemical Composition and Mechanical Property Analysis: Third-party testing reports

Surface Inspection: Visual and microscopic inspection for defects

Ultrasonic Testing: Detection of internal defects

Why Choose Us

Extensive Experience: Located in Baoji, China's Titanium Valley, we possess unparalleled experience in titanium manufacturing.

Global Coverage: We provide consistently high-quality products to customers in Australia, South Korea, Germany, the USA, the UK, Malaysia, and the Middle East.

Quality Commitment: We never compromise on quality and are responsible for every product we manufacture.

Technical Support: Our engineering team provides comprehensive support from material selection to application guidance.

Email: lucky@bjfreelong.com

WhatsApp: +13369210303

Contact us for detailed quotations and technical specifications. We look forward to becoming your trusted high-end titanium materials partner.
